Cross Sectional Thoracic and Abdominal Pictures

1

Sternum

2

Trachea

3

Esophagus

4

Spinal cord

5

Left scapula

6

Left humeral shaft

7

Left lung

8

Aortic arch

1

ascending aorta

2

superior vena cava

3

rib

5

descending aorta

6

pulmonary artery

1

ascending aorta

2

superior vena cava

4

rib

5

pulmonary trunk

6

Thoracic vertebrae

7

Descending aorta

8

Spinous process

1

ascending aorta

2

right superior pulmonary vein

3

right inferior pulmonary vein

4

pericardium

1

dome of liver

2

diaphragm

3

inferior lobe of right lung

4

mammary gland

5

interventricular septum

6

descending aorta

1

breast tissue

2

inferior vena cava

3

liver

4

apex of heart

5

esophageal sphincter

6

stomach

7

descending aorta

4

superior vena cava

5

diaphragm

6

esophagus

7

trachea

8

ascending aorta

9

pulmonary trunk

10

pericardium

1

brachiocephalic artery

2

superior vena cava

3

right atrium

4

inferior vena cava

5

left common carotid artery

6

left subclavian artery

7

aortic arch

8

epicardial fat

9

apex of heart

1

liver

2

inferior vena cava

3

spinal cord

4

thoracic vertebrae

5

descending aorta

6

spleen

7

stomach

1

rib

2

diaphragm

7

falciform ligament

2

gallbladder

3

distal lobe of liver

5

left kidney

6

ulna

7

radius

8

pancreas

1

large intestine

3

lumbar vertebrae

4

renal pelvis

5

left ureter

6

small intestine

1

gluteus minimus muscle

2

gluteus medius muscle

3

gluteus maximus muscle

4

sacral foramen

5

sacrum

6

left sacroiliac joint

1

right superior pubic rami

3

coccyx

4

distal sigmoid colon

5

uterus

6

acetabulum

7

head of left femur

8

urinary bladder
