9 Terms

1
New cards

What is a capacitor?

A capacitor consists of two pieces of metal separated by a dielectric material

2
New cards
<p><span>A. Look at the diagram. When the switch is closed, which of the following statements about the capacitor will be true?</span></p>

A. Look at the diagram. When the switch is closed, which of the following statements about the capacitor will be true?

The charge on the capacitor will increase and the potential difference across it will increase

3
New cards

When the capacitor is fully charged, the potential difference across it will be:

Equal to the e.m.f. of the cell

4
New cards

The capacitance C of a capacitor that stores a charge Q with a potential difference V is given by:

C=Q/V

5
New cards

B. The unit of capacitance is the Farad. One Farad is equal to:

1CV-1

6
New cards

What will happen to the capacitance if the potential difference is doubled?

The capacitance will stay the same

7
New cards

The diagram below shows a cell and two capacitors.

post question image

What can we say about the charge stored by each capacitor in series?

The charge stored by each capacitor is the same

8
New cards

The diagram below shows a cell and two capacitors.

post question image

If the capacitors have capacitances of C1 and C2 respectively, what is the total capacitance C across both capacitors?

same equation as resistors in parallel

9
New cards

Select all the correct statements about a capacitor

The negative charge on one plate is equal to the positive charge on the other
