Week 2 - Imaging of Thorax (P1)
Studied by 1 person
Knowt Play
Learn
Practice Test
Spaced Repetition
Match
Flashcards1/127
There's no tags or description
Looks like no tags are added yet.
Name | Mastery | Learn | Test | Matching | Spaced |
|---|
No study sessions yet.
128 Terms
What is structure 1?
Aorta
What is structure 4?
Central tendon of diaphragm
What is structure 11?
IVC/cavial hiatus
What is structure 12?
Left crus of diaphragm
What is structure 14?
Median arcuate ligament
What is structure 15?
Oesophageal hiatus
What is structure 18?
Right crus of diaphragm
What is structure 19?
Spinal cord
Components of caval hiatus (T8)
Inferior vena cava
Terminal branches of right phrenic nerve
Components of oesophageal hiatus (T10)
Oesophagus
Right and left vagus nerves
Oesophageal branches of left gastric artery/vein
Components of aortic hiatus (T12)
Aorta
Thoracic duct
Azygous vein
What is structure 2?
Brachiocephalic trunk
What is structure 11?
Left brachiocephalic vein
What is structure 12?
Left common carotid
What is structure 13?
Left external jugular vein
What is structure 14?
Left internal jugular vein
What is structure 15?
Left lung
What is structure 16?
Left phrenic nerve
What is structure 17?
Left recurrent laryngeal nerve
What is structure 18?
Left subclavian vein
What is structure 19?
Left vagus nerve
What is structure 26?
Right brachiocephalic vein
What is structure 28?
Right external jugular vein
What is structure 29?
Right internal jugular vein
What is structure 30?
Right lung
What is structure 31?
Right phrenic nerve
What is structure 32?
Right recurrent laryngeal nerve
What is structure 33?
Right subclavian vein
What is structure 34?
Right vagus nerve
What is structure 36?
Superior vena cava
What is structure 37?
Trachea
What is structure 1?
Azygous vein
What is structure 5?
First rib
What is structure 8?
Oesophagus
What is structure 9?
Right atrium (w/ pericardium)
What is structure 11?
Right internal thoracic artery
What is structure 13?
Right phrenic nerve
What is structure 14?
Right primary bronchus
What is structure 15?
Right pulmonary artery
What is structure 16?
Right subclavian artery
What is structure 17?
Right subclavian vein
What is structure 18?
Right superior pulmonary vein
What is structure 19?
Right vagus nerve
What is structure 21?
Right posterior intercostal vein
What is structure 22?
Superior intercostal vein
What is structure 24?
Superior vena cava
What is structure 28?
Trachea
What is structure 3?
Aortic arch
What is structure 8?
Hemi-azygous vein
What is structure 9?
Left brachiocephalic vein
What is structure 10?
Left common carotid artery
What is structure 11?
Left inferior pulmonary vein
What is structure 12?
Left internal thoracic artery
What is structure 13?
Left internal thoracic vein
What is structure 14?
Left phrenic nerve
What is structure 15?
Left primary bronchus
What is structure 16?
Left pulmonary artery
What is structure 17?
Left recurrent laryngeal nerve
What is structure 18?
Left subclavian artery
What is structure 22?
Left vagus nerve
What is structure 23?
Left ventricle
What is structure 29?
Subclavian vein
What is structure 32?
Thoracic aorta
What is structure 2?
Axillary vein
What is structure 3?
Sternoclavicular joint
What is structure 4?
Manubrium
What is structure 5?
Brachiocephalic artery
What is structure 6?
Left common carotid artery
What is structure 7?
Trachea
What is structure 8?
Left subclavian artery
What is structure 9?
Oesophagus
What is structure 10?
Left lung
What is structure 12?
Body of T3 vertebrae
What is structure 13?
Spinal cord
What is structure 16?
Scapula
What is structure 2?
Superior vena cava
What is structure 3?
Pectoralis major muscle
What is structure 4?
Thymus
What is structure 5?
Manubrium
What is structure 6?
Aortic arch
What is structure 7?
Oesophagus
What is structure 10?
Body of T4 vertebrae
What is structure 11?
Spinal cord
What is structure 12?
Azygos vertebrae
What is structure 13?
Right lung
What is structure 14?
Trachea
What is structure 3?
Ascending aorta
What is structure 4?
Body of sternum
What is structure 5?
Costal cartilage
What is structure 6?
Pulmonary trunk
What is structure 7?
Left pulmonary artery
What is structure 8?
Left lung
What is structure 11?
Scapula
What is structure 12?
Descending aorta
What is structure 13?
Body of T5 vertebrae
What is structure 15?
Spinal cord
What is structure 17?
Oesophagus
What is structure 18?
Right main bronchus
What is structure 19?
Right pulmonary artery
What is structure 20?
Superior vena cava
Note
Flashcards (54)
