10 Terms
1
New cards
PE
PE = mgh
2
New cards
KE
KE = ½ mv² = ½ m(v2² - v1²)
3
New cards
Wk2-3 of hammer
Wk2-3 = (W-f) Distance = KE3 - KE2 = 0 - KE2 → (W-f) * Distance = - KE2
4
New cards
Steady State Energy Balance
5
New cards
Alternate Method Energy Balance
6
New cards
enthalpy, internal energy, specific volume, pressure
h = u + pv
7
New cards
Heat Formula
8
New cards
Pressure and Temperature Relation
P2/P1 = T2/T1
9
New cards
headloss between two gauges
h = (P1-P2)/δ
10
New cards
Specific Weight of Fluid
δ = SG x γ of water = SG x 9.81
