Complete Denture - Fabrication Steps and Competency PDF

Which denture fabrication appointment number does the following occur at?

- Diagnostic/Preliminary Impression

1

Which denture fabrication appointment number does the following occur at?

- Border molding and final impression

2

Which denture fabrication appointment number does the following occur at?

- Adjustment of wax rims, facebow record

- CR registration teeth selection

3

Which denture fabrication appointment number does the following occur at?

- Verification of CR and anterior teeth set-up try in

Optional step between 3 and 4

Which denture fabrication appointment number does the following occur at?

- Full set-up try in

4

Which denture fabrication appointment number does the following occur at?

- Denture insertion

5

Which denture fabrication appointment number does the following occur at?

- Follow up

6+

Which denture fabrication appointment number does the following occur between?

- Pouring the casts, basing, trimming

- Fabrication of custom trays

Between 1 and 2

Which denture fabrication appointment number does the following occur between?

- Boxing, pouring, and trimming of casts

- Fabrication of record bases and wax rims

Between 2 and 3

Which denture fabrication appointment number does the following occur between?

- Mounting

- Teeth set-up

Between 3 and 4

Which denture fabrication appointment number does the following occur between?

Denture processing and polishing

Between 4 and 5

For the CD comp, what were the measurements for the anterior teeth section on the wax rim (#1 in image)?

5-8 mm

For the CD comp, what were the measurements for the posterior teeth section on the wax rim (#2 in image)?

8-12 mm

What should the wax NOT cover at the blue arrow?

Tuberosity

What is the anterior height from the top to the vestibule in the maxillary arch?

22 mm

What is the posterior height from the top to the vestibule in the maxillary arch?

20 mm

What is the anterior height from the top to the vestibule in the mandibular arch?

18 mm

What is the posterior height from the top to the vestibule in the mandibular arch?

2/3 height of retromolar pad (+/-1mm)

How should the wax present in relation to the vestibule?

- Labial surface should NOT exceed the vestibule

- Rim should be straight up

- Wax covers all the way down to the flange

What should the mandibular wax rim be centered over?

Wax rim should be centered buccolingually over the posterior ridge

Which line marks the center of the ridge?

Red line (teal is the raphe)

All of the following should be included when finishing the CD comp except...

A) No wax between triad and cast

B) Well-defined corner

C) Smooth, flat surface

D) Voids

D) Voids
