PVC

2 SCH 40 PVC 90 ELB SOC

use: allows for change of direction in pipe

code = 2 90 elb

2 SCH40 PVC CPLG SOC

use: fitting connects two pieces of pipe

• codos de 90 con conexcion enchufe

code = 2 pd cp

2 SCH40 PVC ADPT MPTxSOC

use: fitting adapts male thread to socket connection

• adaptadores machos de pvc con enchufe

code = 2 sch40 adpt

3×4 PVC CLST FLG

use: connects toilet to drain pipe

• brida de inodoro o reborde = closet flange

code = 3×4 clst

2×3/4 SCH40 PVC BUSH SPGxFTG

use: reducer bushing that connects PVC fitting into a threaded PVC component. commonly used in cold water applications

SPG = Spigot : male, unthreaded connection. designed to be glued into a larger female fitting

FTG = female threaded connection

• buje reductor o casquillo reductor = reducing bushing

• espiga = spigot

code = 2×34 PVC

OATEY 1 ¼ PVC TUBULAR P TRAP

use: under sink plumbing to prevent sewer gases from entering into house

• trampa p de pvc

• sifon = p-trap

code = bagged

PVC 1 ½ DWV TRAP ADPT W/ PLASTIC NUT & WASH HUBxSLIP

use: connects tubular drain to a DVW system, allows for future adjustments without cutting pipe

• adaptador para sifon/trampa de pvc

• tuerca plastica y arandela = plastic nut and washer

code = pd 112 trap ad

PVC 2 DVW WYE HUB

use: connects one or more branch lines into a main horizontal drain line

code = pd2y

4 INSIDE PIPE FIT CLEANOUT

use: has removable cover that allows access to pipe for clearing blockages

4 = fits inside a 4” PVC pipe

code = 4 pipe clean

PVC 3 DVW CPLG HUB

use: connects two PVC pipes with hub ends which allow for pipes to be entered into the cplg

code: pd 3 cp

PVC 2 DWV P-TRAP HUB

use: used under skinks, tubs and showers to trap water in the bend and block sewer gases and clogging

code = pd 2 pt

PVC 2 DWV45 ST ELB HUBxSPG

use: fitting changes the direction of flow by 45 degrees

one side receives a pipe, and spigot end fits into another hub

st = straight side

code = pd 245 st

PVC 3×3×1 ½ DWV SAN TEE RED HUB

use: has two 3” hub connections and one 1 ½ allowing for flow into main vertical drain

RED = reducing, main line is 3” but is reduced to 1 ½ “

code = red st 112

¾ CPVCG CPLG SxS

use: joins two lengths of CPVC pipe

SxS = Slip x Slip, both ends are hub-style sockets that accept CPVC pipe

code = 34 cp cpvc

¾ CPVCG 90 ELL SxS

use: creates right angle turn in CPVC pipe system

code = 34 90 cpvc

1 ½ DEEP SOCKET TECHNO CAP

use: seals pipe ends mainly when pipe is cut at slight angle giving it a secure fit

deep socket = allows for 1 inch deep solvent weld socket, gives extra bonding surface

code = 112 deep

¾ CPVCG (CTS) STREET 90 ELL SPGxS

use: changes direction of CPVC pipe run by 90 degrees, saves space in tight spaces

code = 34 st elb

2 PVC SHWR DRN F/FG W/SS STRN

use: connects shower base to plumbing system, has a PVC body

F/FG = Fiberglass

code = drn w strn

VLV QUIET CHECK 2 PVC/UNION/BV/SOC/WHT

use: designed to prevent backflow and reduce noise in plumbing systems

UNION = connection allow easy removal/maintenance without need to cut pipes

code = vlv check

4×3 CPVC SCH80 RED BUSH SPGxS

use: reduce pipe size

SCH80 = gray, thicker for higher pressure

code = 4×3 sch80

IPS REDI-VENT BULK PVC

use: air admittance valve for vent plumbing fixtures without needing vent pipe through roof, prevent sewer gases

code = redi

PVC 3 DWV 22 ½ ST ELB HUBXSPG

use: plumbing fitting that has a 22.5 degree bend

SPIGOT = fits inside of another

HUB = receives pipe

PVC 3×2 DWV FL BUSH SPGxHUB

use; reduces pipe size while maintaining flow

bush fitting is a reducer fitting, sits flush inside another pipe

code = pd 3 bush or pd 3 redb

1 ½ x 16 DBL FLG TLPC PVC

use: connects sink strainer to p-trap, and allows for slip-point connections with no need for threading or glue

code = tail
