Electric Field, Electrostatic Potential, Electrostatic Potential Energy

Study Analytics
Name
Mastery
Learn
Test
Matching
Spaced

No study sessions yet.

7 Terms

1
New cards

Definition of Electric Field?

Electric field is sthe region in which a test charge can experience an electric force due to the presence of a source charge.

2
New cards

What is Electric Field Strength?

Electric field strength at a point is equal to the force experienced by unity positive test charge.

3
New cards

The two formulae for Electric Field are? (vector forms please)

knowt flashcard image
4
New cards

Formula for electric field due to a charged circular arc at its centre?

knowt flashcard image
5
New cards

Formula for electric field due to a charged ring at a point on its axis?

knowt flashcard image
6
New cards

If there is a charged ring, how far along its axis from the centre will give maximum electric field? What will the magnitude of the electric field be at that point

<p></p>
7
New cards
