CLAVICLE/AC JOINT

how is the CR angled for a AP projection clavicle

no angle

how is the CR angled for a AP axial projection clavicle

15-30 cephaled

what are the breathing instructions for clavicles

suspend for inspiration

who needs a greater angulation for clavicles

asthenic/slender people

what is this

AP clavicle

what is this

AP axial clavicle

what is the MCP in a AP clavicle

parallel

what is superimposed in a AP clavicle

scapular angle

in an AP axial clavicle is anything superimposed

no

what is wrong with this AP clavicle

rotated to the left (unaffected side), superimpostition of the clavicle and vertebral column

what is the relationship between clavicle and vertebral column

inverse

how do you fix this AP clavicle

rotate to the right

how do you fix this AP clavicle

rotate to the right

what is wrong with this AP clavicle

rotated to teh affected side

how many radiographs for a unilateral AC joint

4

how many radiographs in bilateral AC joint

2

what ist he SID for a unilateral AC joint

100

what is the SID for bilateral AC joint

180

what is the breahting instructions for AC joint

suspended

where is CR for AC joint with weight unilateral

2.5 below AC joint

where is CR for AC joint with weight biilateral

2.5 above jugular notch
