8 Terms

1
New cards

What is Ohm’s Law?

V = I x R (Voltage = Current x Resistor)

2
New cards

State Kirchhoff’s Current Law (KCL).

The sum of currents entering a node equals the sum of currents leaving the node.

3
New cards

State Kirchhoff’s Voltage Law (KVL).

The total voltage around any closed loop or mesh in a circuit must equal zero.

4
New cards

What is the formula for Power?

P = V x I, P = (V)²/R, P = R(I)²

5
New cards

Series Resistor Formula

<p></p>
6
New cards

Two Resistors in Parallel Formula

knowt flashcard image
7
New cards

Resistors in Parallel Formula

knowt flashcard image
8
New cards

What is the Energy Formula?

E = P x t
