Unit 2 Lab/ Skeletal system

synarthrosis

immovable joints that fuse overtime

what is this bone and where is it located?

hyoid; front of upper neck

what is the neon pink stucture?

vomer

what is the dark blue structure?

ethmoid

what is the blue highlighted bone?

maxilla

what is the yellow indicated stucture?

alveolar margins

what is the light blue structure?

inferior nasal concha

what are the red circled structures?

infraorbital foramen

what is the purple circled structure?

orbitals

what is the dark green notch on the orbitals?

supraorbital foramen

what is the orange structure?

superior orbital fissure

what is the green structure?

inferior orbital fissue

what is the yellow highlighted bone?

nasal

what is the pink highlighted bone?

frontal

what is this bone?

mandible

what structure is M?

mental foramen

what is red highlighted structure?

mental protuberance

what structure is H?

mandibular condyle

what structure is G?

coronoid process

what structure is L?

mandibular ramus

what is the pink structure?

mandibular notch

what is structure A?

mandibular foramen

what is the pink highlighted bone?

zygomatic

what is the blue highlighted bone?

temporal

what is the red indicates structure?

zygomatic arch

what is the yellow circled structure?

external acoustic meatus

what is the pink circled structure?

mastoid process

what is green highlighted bone

parietal

what is the dark green indicated suture?

coronal suture

what is the purple indicated suture?

sagittal suture

what is the dark blue indicated suture?

squamous suture

what is light blue indicated suture?

lambdoid suture

what is the red circled structure?

magnum foramen

what is the highlighted pink bone?

occipital bone

what is the light blue circled stucture?

occipital protuberance

what are the yellow circled stuctures?

occipital condyles

what do the occipital condyles interact with?

vertebrae and creates a hinge joint

what is the purple highlighted bone?

palatine

what is the purple highlighted bone?

ethmoid

what is the blue highlighted bone?

sphenoid

what is the green highlighted bone?

temporal

what is the pink highlighted bone?

occipital

what is the orange highlighted bone?

frontal

what is the light blue structure?

crista galli

what is the dark yellow stucture?

cribriform plate

what is the red circled structure?

optical canal

what is the pink indicated structure?

orbital fissures

what is the orange circled structure?

foramen rotunda

what is the light green circled structure?

foramen spinosum

what is the dark green circled structure?

foramen lacerum

what is the dark blue indicated structure?

sella turcica

what is the neon green circled structure?

internal acoustic meatus

what is the maroon circled structure?

jugular foramen

what is the neon yellow circled structure?

hypoglaso canal

what vertebrae is transverse foramen unqiue too?

cervical

what vertebrae is this?

cervical

what is the blue circled structure?

transverse foramen

what is the red circled structure?

vertebral body

what is the pink indicated structure?

lamina

what is the purple indicated structure?

spinous process

what is the green structure?

pedicle

what is the orange circled structure?

superior articulating faucet (inferior)

what kind of vertebrae is this?

lumbar

what kind of vertebra is this?

thoracic

what is the red indicated structure?

spinous process

what is the yellow indicated structure?

articular facuet

what is the large opening in the middle of the vertebrae?

vertebral foramen

what is this vertebrae called?

axes (C2)

what is the blue circled stucture?

dens

what vertebrae is this?

atlas (C1)

what is purple circled structure?

anterior facet for dens

what is the blue highlighted bone?

sacrum

what is the purple highlighted bone?

coccyx

what is the red circled structure?

entrance to sacral canal

what is orange circled structure?

articular process

what is pink circled structure?

sacral hiatus

what is yellow circled structures?

sacral foramina

what is blue structure?

median sacral crest

what bone is this?

sternum

what is the green section?

maneuverum

what is the orange section?

sternal body

what is the pink section?

xiphoid process

what is the blue circled structure?

jugular notch

what is the yellow circled structure?

clavicular notch

what is the red indicated structure?

costal cartilages

what ribs are the pink highlighted ones?

7 true ribs

what ribs are the dark green highlighted ones?

3 false ribs

what ribs are the blue highlighted ones?

3 floating ribs

what are the orange structures?

costal articulation

what are the light green structures?

sternal end

what are the purple circled structures?

head of ribs

what is this bone?

ulna

what is the red structure?

olecranon process

what is the dark blue structure?

trochlear notch

what is the light blue structure?

coronoid process

what is the yellow circled structure?

radial notch

what is the pink circled structure?

ulnar tuberosity

what is the purple structure?

syloid process

what bone is this?

clavicle

what is the red structure?

sternal end (more blunt end)
