36 Terms

1
New cards
<p>1?</p>

1?

Eyepiece/ocular lens

<p>Eyepiece/ocular lens</p>
2
New cards
<p>2?</p>

2?

Diopter adjustment

<p>Diopter adjustment</p>
3
New cards
<p>3?</p>

3?

Arm

<p>Arm</p>
4
New cards
<p>4?</p>

4?

Coarse adjustment/focus

<p>Coarse adjustment/focus</p>
5
New cards
<p>5?</p>

5?

Fine adjustment/focus

<p>Fine adjustment/focus</p>
6
New cards
<p>6?</p>

6?

On/Off switch

<p>On/Off switch</p>
7
New cards
<p>7?</p>

7?

Nose piece

<p>Nose piece</p>
8
New cards
<p>8?</p>

8?

Objective lens

<p>Objective lens</p>
9
New cards
<p>9?</p>

9?

Stage clip/slide holder

<p>Stage clip/slide holder</p>
10
New cards
<p>10?</p>

10?

Stage

<p>Stage</p>
11
New cards
<p>11?</p>

11?

Condenser

<p>Condenser</p>
12
New cards
<p>12?</p>

12?

Iris diaphram

<p>Iris diaphram</p>
13
New cards
<p>13?</p>

13?

Light source/illuminator

<p>Light source/illuminator</p>
14
New cards
<p>14?</p>

14?

Base

<p>Base</p>
15
New cards

Ocular lens

Located in the eyepiece, and usual magnification is 10x

16
New cards

Objective lens

Located above the stage, and typically has multiple stages of magnification

17
New cards

What are the objective lenses on our microscopes?

4x (red line), 10x (yellow line), 40x (blue line), 100x (white line)

18
New cards

What is the 4x?

Scanning objective lens

19
New cards

What is the 10x?

Low power objective lens

20
New cards

What is the 40x?

High dry objective lens

21
New cards

What is the 100x?

Oil immersion objective lens

22
New cards

Eyepiece

Portion of the microscope you look in

23
New cards

Eye guard(s)

Located on the eyepiece; reduces ambient light and glare; provides comfort and maximum visual effectiveness; assures proper eye to lens positioning

24
New cards

Diopter adjustment

Adjusts focus to compensate for the visual differences between your eyes

25
New cards

How is total magnification calculated?

Multiply objective lens power by ocular lens power

26
New cards

Stage

Where the slide is placed

27
New cards

Stage control

Moves stage front to back and side to side

28
New cards

Stage clips

Holds slide on the stage

29
New cards

Coarse adjustment

Moves stage up and down in large movements; do not use for objective lenses above 10x (4x and 10x only)

30
New cards

Fine adjustment

To fine tune view and look through the layers of the object in view

31
New cards

What should you always do when viewing through a microscope?

Keep your hand on the fine adjustment

32
New cards

Light source/illumination

Illuminates the slide

33
New cards

Condenser/aperture (iris) diaphragms

Adjusts brightness of light source/illumination (typically need higher brightness for higher magnification); Concentrates light with uniform intensity over the entire view-field

34
New cards

How do objects viewed in a microscope appear?

Reversed and upside down

35
New cards

What are the steps for putting away the microscope?

Turn light off, move 4x objective into place, lower stage completely, remove slide, clean oil immersion lens if necessary, cover with dust cover

36
New cards

What do you use to clean the microscope lenses?

Lens paper
