6 Terms

1
New cards
<p><span style="color: rgb(0, 0, 0);"><span>Label This Diagram</span></span></p>

Label This Diagram

a - thermometer

b - lid

c - insulator

d - cold water

e - calorimeter

f - steam bubbles

g - glass tubes

h - steam trap

i - steam

j - boiling water

2
New cards

Demonstrate the method of this experiment (1)

Measure mass of calorimeter

3
New cards

Demonstrate the method of this experiment (2)

Add cold water

Measure mass of calorimeter + water

Measure initial temperature

4
New cards

Demonstrate the method of this experiment (3)

Boil water

Measure final temperature

Measure mass of calorimeter + water + steam

5
New cards

Define the formula used for this experiment

m (i) l (vw) + m(s) c(w) temp change (s) = m (w) c (w) temp change (w+c) + m (c) c (c) temp change (w + c)

6
New cards

Name 2 precautions associated with this experiment

  1. Room temperature between initial temperature and 100°C

  2. Use steam trap to ensure only steam is added
