17 Terms
What are the two types of electricity?
Static and Dynamic
What is Static Electricity? (Give 4 charac)
Stationary
One a Time
Air
Open Circuit
What is Dynamic Electricity? (Give 4 charac)
Moving
Cycle
Conductor
Closed Circuit
What do you call the static electricity?
Electric Flux
What do you call the dynamic electricity?
Current
What is Coulombs Law?
It gives you the force between two charges
What is the formula for Coulombs Constant?
What is electric field?
The electric influence around a charge that can push or pull another charge.
What is electrostatic force?
The push or pull experienced by a charge because of another charge.
What is Electric Flux?
The amount of electric field passing through a surface.
What is electric field intensity?
how strong the electric field is at that location.
What is the unit of Electric field, Electric field intenstiy, Electric flux, Electrostatic force, and Electric flux density?
Electric Field - N/C or V/m
Electric Field Intensity - N/C or V/m
Electric Flux - Nm²/C
Electrostatic Force - N
Electric Flux Density - C/m²
What is the formula for electric field/intensity?
What is the formula for electrostatic force?
What is the formula for Electric flux density ?
What is the formula for Electric flux?
What is electric flux density?
how much electric flux is concentrated over a given area.
