PPOM 2 OMM Practical 1: Cranial Strain Patterns

Reference handouts for Labs 3 and 4. Jazz Hands!

Flexion - Air Hand Model

“Swelling”. The operator’s hands move towards the feet, palms move laterally, fingers spread.

Extension - Air Hand Model

“Receding”. The operator’s hands move cephalad, palms move medially, and fingers move slightly together.

Right Torsion - Air Hand Model

Hands rotate in opposite directions. Hand rotates cephalad on right side (side of the higher Greater Wind of Sphenoid).

Left Torsion - Air Hand Model

Hands rotate in opposite directions. Hand rotates cephalad on left side (side of the higher Greater Wind of Sphenoid).

Right Sidebending and Rotation - Air Hand Model

Hand moves caudally with fingers spreading out on side of convexity (right); Hand moves cephalad with fingers approximating on side of concavity (left).

Left Sidebending and Rotation - Air Hand Model

Hand moves caudally with fingers spreading out on side of convexity (left); Hand moves cephalad with fingers approximating on side of concavity (right).

Right Lateral Strain - Air Hand Model

Index fingers move left (towards Greater Wings of Sphenoid) while pinkies move right

Left Lateral Strain - Air Hand Model

Index fingers move right (towards Greater Wings of Sphenoid) while pinkies move left

Superior Vertical Shear - Air Hand Model

Fingers point down towards feet. Hands rotate anteriorly

Inferior Vertical Shear - Air Hand Model

Fingers point up towards head. Hands rotate posteriorly

SBS Compression - Air Hand Model

Either Feels rock-hard like a bowling ball or feels like all the cranial patterns at once

Flexion - Physiologic or Non Physiologic?

Physiologic

Extension - Physiologic or Non Physiologic?

Physiologic

Right Torsion - Physiologic or Non Physiologic?

Physiologic

Left Torsion - Physiologic or Non Physiologic?

Physiologic

Right Sidebending and Rotation - Physiologic or Non Physiologic?

Physiologic

Left Sidebending and Rotation - Physiologic or Non Physiologic?

Physiologic

Right Lateral Strain - Physiologic or Non Physiologic?

Non Physiologic

Left Lateral Strain - Physiologic or Non Physiologic?

Non Physiologic

Superior Vertical Shear - Physiologic or Non Physiologic?

Non Physiologic

Inferior Vertical Shear - Physiologic or Non Physiologic?

Non Physiologic

SBS Compression - Physiologic or Non Physiologic?

Non Physiologic

Flexion - Axes

2 transverse axes

Extension - Axes

2 transverse axes

Right Torsion - Axes

1 Anterior/Posterior Axis

Left Torsion - Axes

1 Anterior/Posterior Axis

Right Sidebending and Rotation - Axes

2 parallel vertical axes (sidebending), 1 Anterior/Posterior Axis (rotation)

Left Sidebending and Rotation - Axes

2 parallel vertical axes (sidebending), 1 Anterior/Posterior Axis (rotation)

Right Lateral Strain - Axes

2 parallel vertical axes

Left Lateral Strain - Axes

2 parallel vertical axes

Superior Vertical Shear - Axes

2 transverse axes

Inferior Vertical Shear - Axes

2 transverse axes

SBS Compression - Axes

No Axes

Flexion - Movement of Occiput & Sphenoid

Move around transverse axes in opposite directions

Extension - Movement of Occiput & Sphenoid

Move around transverse axes in opposite directions

Right Torsion - Movement of Occiput & Sphenoid

Move around 1 Anterior/Posterior axis in opposite directions, name for side of high GW (right)

Left Torsion - Movement of Occiput & Sphenoid

Move around 1 Anterior/Posterior axis in opposite directions, name for side of high GW (left)

Right Sidebending and Rotation - Movement of Occiput & Sphenoid

Sidebending: Move in opposite directions around parallel vertical axes

Rotation: Move in same direction around Anterior/Posterior axis

Left Sidebending and Rotation - Movement of Occiput & Sphenoid

Sidebending: Move in opposite directions around parallel vertical axes
Rotation: Move in same direction around Anterior/Posterior axis

Right Lateral Strain - Movement of Occiput & Sphenoid

Move around vertical axes in same direction

Left Lateral Strain - Movement of Occiput & Sphenoid

Move around vertical axes in same direction

Superior Vertical Shear - Movement of Occiput & Sphenoid

Move around transverse axes in same direction

Inferior Vertical Shear - Movement of Occiput & Sphenoid

Move around transverse axes in same direction

SBS Compression - Movement of Occiput & Sphenoid

N/A

Identify the Cranial Strain Pattern:

Flexion

Identify the Cranial Strain Pattern:

Extension

Identify the Cranial Strain Pattern:

Right Torsion

Identify the Cranial Strain Pattern:

Left Torsion

Identify the Cranial Strain Pattern:

Right Sidebending and Rotation

Identify the Cranial Strain Pattern:

Left Sidebending and Rotation

Identify the Cranial Strain Pattern:

Right lateral strain

Identify the Cranial Strain Pattern:

Left lateral strain

Identify the Cranial Strain Pattern:

Superior Vertical Shear

Identify the Cranial Strain Pattern:

Inferior Vertical Shear

Identify the Cranial Strain Pattern:

SBS Compression
