Conus medullaris

Filum terminale

Cauda equina

CN II

CN III

CN I

CN VI

CN IV

CN V

CN IX

CN VIII

CN VII

CN XII

CN XI

CN X
CN I
Olfactory
CN II
Optic
CN III
Oculomotor
Olfactory
Smell (Sensory)
Optic
Sight (Sensory)
Oculomotor
Eye movement and pupil dilation (upward eye roll) (Motor)
CN IV
Trochlear
CN V
Trigeminal
CN VI
Abducens
Trochlear
Eye movement (downward/inward roll) (Motor)
Trigeminal
Touch sensation on face and chewing/biting down (Both)
Abducens
Lateral eye movement (Motor)
CN VII
Facial
CN VIII
Vestibulocochlear
CN IX
Glossopharyngeal
Facial
Facial expression/smile and taste (Both)
Vestibulocochlear
Hearing and balance (Sensory)
Glossopharyngeal
Taste sensation, swallowing, baro- and chemo- reception, salvation (Both)
CN X
Vagus
CN XI
Accessory
CN XII
Hypoglossal
Vagus
Speaking/voice, internal organ control (Both)
Accessory
Shoulder shrug/ movement below neck (Motor)
Hypoglossal
Tongue movement (motor)
Eyes looking up (left, straight, or right)
M: Superior rectus, inferior oblique
N: Oculomotor
Eyes looking left or right
Medial rectus (oculomotor), lateral rectus (abducens)
Eyes looking down (left, straight, or right)
Inferior rectus (oculomotor), superior oblique (trochlear)

Supraorbital foramen/notch

Frontal bone

Temporal bone

LOWER arrow
Styloid process

Parietal bone

HIGHER arrow
External acoustic (auditory) meatus

Occipital bone

Occipital condyles

Sphenoid bone

Hypophyseal fossa (Sella turcica)

Zygomatic bone

Zygomatic arch

Infraorbital foramen

Maxillary bone

WHOLE highlighted region
Ethmoid bone

Arrow
Crista galli

Lacrimal bone

Palatine bone

Nasal bone

Vomer bone

ENTIRE bone
Mandible bone

Bottom two arrow to the right
Body

Top right arrow (barely can see)
Coranoid process

Left middle arrow
Ramus

Top left arrow
Condyle (head)

Top arrow
Coronal suture

Middle arrow
Sagittal suture

Bottom arrow
Lambdoid suture

Middle arrow
Squamous suture

Top arrows
Superior orbital fissure

Bottom arrows
Inferior orbital fissure

1 and 2
Superior and inferior fissures

3
Optic canal

4
Foramen rotundum

5
Foramen ovale

6
Carotid canal

7
Internal acoustic (auditory) meatus

9
Jugular foramen

10
Foramen magnum
