Histology Final Revision

This set will help you during your revision in practical exams

THIS PHOTO REPRESENTS

The Cell membrane (TEM)

LETTER “A” REPRESENTS:

Plasma Membrane

THIS PHOTO REPRESENTS

Mitochondria (TEM)

THIS PHOTO REPRESENTS

Mitochondria (TEM)

LETTER “A” REPRESENT

Central Vein

THIS PHOTO REPRESENTS

Mitochondria stained With Iron HX In Liver

YELLOW ARROWS ARE REPRESENTING

Mitochondria appearas small dots inside hepatocytes

THIS PHOTO REPRESENTS

Rough Endoplasmic Reticulum (RER) TEM

THIS PHOTO REPRESENTS

Smooth Endoplasmic Reticulum (SER) TEM

THIS PHOTO REPRESENTS

Smooth Endoplasmic Reticulum (SER) TEM

THIS PHOTO REPRESENTS

Golgi Apparatus “Silver stain”

YELLOW ARROWS ARE POINTING TO

Golgi appears near to the lumen of the Epididymal tubules

YELLOW ARROWS ARE POINTING TO

Transversly cutepididymal tubules

IGNORING ARROWS THIS PHOTO PRESENTS

Golgi Apparatus “TEM”

ARROWS ARE POINTING TO

Golgi saccules

IF YOU KNOW LETTER A IS AN ORGANELLE’S FACE , SO “A” REPRESENTS

Trans Face.

IF YOU KNOW LETTER B IS AN ORGANELLE’S FACE , SO “B” REPRESENTS

Cis Face.

IF YOU KNOW LETTER D IS AN ORGANELLE’S VESICLES , SO “D” REPRESENTS

Secretory Vesicles

IF YOU KNOW LETTER D IS AN ORGANELLE’S VESICLES , SO “C” REPRESENTS

Transfer Vesicles

THIS PHOTO REPRESENTS

Lysosomes (TEM)

THIS PHOTO REPRESENTS

Lysosomes (TEM)

Lysosomes are

Heterogenous variable electron density

THIS PHOTO REPRESENTS

Cilia (TEM)

THIS PHOTO REPRESENTS

Cilia (SEM)

THIS PHOTO REPRESENTS

Cilia (SEM)

THIS PHOTO REPRESENTS

Cilia-Shaft (TEM)

THIS PHOTO REPRESENTS

Centriole (TEM)

THIS PHOTO REPRESENTS

Glycogen PAS Stain in Liver

LETTER “A” REPRESENTS

Central Vein

THOSE THREE BLACK ARROWS ARE POINTING

Magenta red granules of glycogen

THOSE TWO BLACK ARROWS ARE POINTING

Fat cells (sudan III)

THIS PHOTO REPRESENTS

Nucleus (TEM)

THOSE RED ARROWS ARE POINTING

Nuclear Pore

THOSE RED ARROWS ARE POINTING

Nuclear Membrane

THIS RED ARROW IS POINTING

Nucleolus

THIS RED ARROW IS POINTING

Peripheral chromatin

THIS BLACK ARROW IS POINTING

Simple squamous epithelium

THIS RED ARROW IS POINTING “RED CIRCLE MIGHT NOT BE AVAILABLE IN REAL EXAM DON’T RELY ON IT”

Simple cuboidal epithelium

THOSE THREE ARROWS OF “A” ARE POINTING

Follicles

THOSE TWO ARROWS OF “B” ARE POINTING

Colloid

THIS BLUE ARROW IS POINTING

Simple columnar epithelium

THIS BLUE ARROW IS POINTING

Simple columnar epithelium

THIS PHOTO REPRESENTS

Pseudostratified columnar ciliated epithelium with goblet cells

LETTER “A” REPRESENTS

Goblet Cell

LETTER “B” REPRESENTS

Cilia

LETTER “C” REPRESENTS

Epithelium

THIS PHOTO REPRESENTS

Stratified squamous Non-keratinized epithelium

THIS PHOTO REPRESENTS

Stratified squamous keratinized epithelium

BLACK ARROW IN PHOTO IS POINTING

Keratin

THIS PHOTO REPRESENTS

Mucus acini

THIS PHOTO REPRESENTS

Serous acini

THIS PHOTO REPRESENTS

Collagen fibers (TEM) Showing axial periodicity

THIS PHOTO REPRESENTS

Macrophage (TEM)

THIS RED ARROW IS POINTING

Lysosomes

THIS PHOTO REPRESENTS

Mast Cell (TEM)

THIS BLUE ARROW IS POINTING

Nucleus

THIS TWO BLUE ARROWS ARE POINTING

Membrane bounded granules

THIS PHOTO REPRESENTS

Plasma Cell

THIS BLUE ARROW IS POINTING

Cart wheel or Clock face Appearance of the nucleus for Plasma Cell

THIS PHOTO REPRESENTS

Compact Bone

LETTER “A” IS REPRESENTING

Bone Marrow

LETTER “A” IS REPRESENTING

Osteocytes

LETTER “B” IS REPRESENTING

Haversian canals

THIS PHOTO REPRESENT

Cancellous Bone

IF YOU KNOW THAT “A” LETTERS ARE ALL THE SAME, THEN “A” REPRESENTS

Bone Marrow

IF YOU KNOW THAT “B” LETTERS ARE ALL THE SAME, THEN “B” REPRESENTS

Irregular Bone Trabeculae

THIS PHOTO REPRESENTS

Osteoclast in Howship’s lacuna

THIS PHOTO REPRESENTS

Skeletal Muscle (L.S)

THIS PHOTO REPRESENTS

Skeletal Muscle (T.S)

THIS PHOTO IS REPRESENTING

Skeletal muscle (TEM)

THIS PHOTO REPRESENTS

Cardiac Muscles

THIS PHOTO REPRESENTS

Cardiac Muscles

THIS PHOTO REPRESENTS

Cardiac Muscles ( TEM )

THIS PHOTO REPRESENTS

Nerve cell stained by Toluidine blue

THIS PHOTO REPRESENTS

Astrocytes stained by GFAP

THIS PHOTO REPRESENTS

Erythrocytes (SEM)

ARROW LABELLED “A” IS POINTING

Eosinophil

ARROW LABELLED “B IS POINTING

Neutrophil

ARROW LABELLED “C” IS POINTING

Basophil

ARROW LABELLED “D” IS POINTING

Lymphocyte

ARROW LABELLED “F” IS POINTING

RBCs

THIS PHOTO REPRESENTS

Aorta (H&E)

AREA LABELLED “A” REPRESENTS

Media Thick

AREA LABELLED “B” REPRESENTS

Adventitia Thin

THIS PHOTO REPRESENTS

Aorta (H&E)

THIS PHOTO REPRESENTS

Medium sized A. & V. (very low power)

ARROW LABELLED “A” REPRESENTS

Medium sized vein

ARROW LABELLED “B” REPRESENTS

Medium sized Artery

THIS PHOTO REPRESENTS

Liver

AREA LABELLED “A” REPRESENTS

Central Vein

THIS PHOTO REPRESENTS

Liver

AREA LABELLED “A” REPRESENTS

Central Vein

THIS PHOTO IS REPRESENTING

Liver - Hepatocytes

THIS PHOTO REPRESENTS

Liver - Portal Area

LETTER “A” IS REPRESENTING

Interlobular Connective Tissue

LETTER “B” IS REPRESENTING

Hepatocytes

LETTER “C” IS REPRESENTING

Branch Of Hepatic Artery

LETTER “D” IS REPRESENTING

Branch Of Portal Vein

LETTER “E” IS REPRESENTING

Branch Of Bile Duct

THIS PHOTO REPRESENTS

Lung
