8 Terms

1
New cards

name collimation for hand

1 inch on all sides of hand, 1 inch proximal to ulnar styloid

2
New cards
<p>name the projection, its required kVp/mAs, and CR placement</p>

name the projection, its required kVp/mAs, and CR placement

pa hand; 66 kVp, .7 mAs; perpendicular to 3rd MCP joint

3
New cards
<p>name the projection, its required kVp/mAs, and CR placement</p>

name the projection, its required kVp/mAs, and CR placement

pa oblique hand; 66 kVp, .8 mAs; perpendicular to 3rd MCP joint

4
New cards
<p>name the projection, its required kVp/mAs, and CR placement</p>

name the projection, its required kVp/mAs, and CR placement

fan lateral hand; 70 kVp, 1.2 mAs; perpendicular to 2nd MCP joint

5
New cards

name collimation for wrist

2.5 inches proximal and distal to wrist joint and 1 inch on the sides

6
New cards
<p>name the projection, its required kVp/mAs, and CR placement</p>

name the projection, its required kVp/mAs, and CR placement

pa wrist; 66 kVp, .9 mAs; perpendicular to midcarpal area

7
New cards
<p>name the projection, its required kVp/mAs, and CR placement</p>

name the projection, its required kVp/mAs, and CR placement

pa oblique wrist; 66 kVp, .9 mAs; perpendicular to midcarpal area, just distal to radius

8
New cards
<p>name the projection, its required kVp/mAs, and CR placement</p>

name the projection, its required kVp/mAs, and CR placement

lateral wrist; 70 kVp, 1.1 mAs; perpendicular to wrist joint
