neuroanatomy exam 4 cross sections and resit lecture notes

what is purple

fornix

whats in light blue

caudate nucleus

whats in dark blue

optic tract

whats in green

lentiform nucleus (putamen and globus pallidus)

whats in orange ( in green section)

putamen

whats in puple

globus pallidus, internal and external componetns

whats in pink of the left

internal capsule (corticospinal and corticobulbar axons run through here)

whats in light blue

caudate nucleus tail

whats in green

substantia nigra

whats in red ( by the tan)

subthalamic nucleus

whats in orange

putamen

whats in pink

hippocampal formation

whats in yellow

subthalamic nucleus

whats in green

globus pallidus, internal and external

whats in salmon

mammilothalamic tract

whats in pink

ventral posteromedial nucleus of thalamus

whats in purple

ventral posterolateral nucleus of thalamus

whats in blue

column of fornix

corticospinal

to LMNs of contralateral spinal cord in the ventral horn

voluntary movement

cell bodies in ipsi motor cortex

corticobulbars

voluntary movement

LMNs to contra or bilateral motor nucleus (III, VII, IX, XII)

vestibular reflexes

ascending MLF

project bilaterally from the vestibular nuclei to the occulomotor nuclei

cardinal division

cerebral aqueduct, crus cerebri, substantia nigra to midbrain
