Ch 6 A tour of the Cell

What are the peremeters of microscopy?

• Magnification

• Resolution

• Contrast

What kind of Microscopy looks like this?

Light Microscopy

What kind of Microscopy looks like this?

Fluorescent Microscopy

What kind of Microscopy looks like this?

Electron Microscopy

Name that Prokaryotic Part

The Fimbriae

Name that Prokaryotic Part

The Nucleoid

Name that Prokaryotic Part

The Ribosomes

Name that Prokaryotic Part

The Plasma membrane

Name that Prokaryotic Part

The cell wall

Name that Prokaryotic Part

The glycocalyx

Name that Prokaryotic Part

The flagella

Name that Prokaryotic Part

The bacterial chromosome

Name that biological membrane part

The Carbohydrate side chains

Name that biological membrane part

The Proteins

Name that biological membrane part

The phosopholipid

Name that biological membrane part

The Hydrophobic region

Name that biological membrane part

The Hydrophilic region

Name that Animal Cell part

The Rough ER

Name that Animal Cell part

The Smooth ER

Name that Animal Cell part

The Nuclear envelope

Name that Animal Cell part

The Nucleolus

Name that Animal Cell part

The Chromatin

Name that Animal Cell part

The Ribosomes

Name that Animal Cell part

The Plasma Membrane

Name that Animal Cell part

The Lysosomes

Name that Animal Cell part

The Mitochondrion

Name that Animal Cell part

The Peroxisome

Name that Animal Cell part

The Microvilli

Name that Animal Cell part

The Endoplasmic reticulum

Name that Animal Cell part

The Nucleus

Name that Animal Cell part

The Cytoskeleton

Name that Animal Cell part

The golgi apparatus

Name that Plant Cell part

The Nucleus

The Name that Animal Cell part

The Rough ER

The Name that Animal Cell part

The smooth ER

Name that Animal Cell part (small purple dots)

The Ribosomes

Name that Animal Cell part

The Central Vacuole

What are the parts of the Cytoskeleton in plant cells?

• microfilaments

• microtubules

Name that Animal Cell part

The Chloroplast

Name that Animal Cell part

The Plasmodesmata

Name that Animal Cell part

The Cell walls

Name that Animal Cell part

The Plasms membrain

Name that Animal Cell part

The Peroxisome

Name that Animal Cell part

The Mitochondria

Name that Animal Cell part

The Golgi apparatus

What are the major differences in plant and animal cells?

Animal cells:

• Glycoprotein extracelluler matric

• Centrioles

• tight junctions, desmosomes, gap junctions

Plant Cells:

• Chloroplasts

• Cell walls (cellulose)

• Large central vacuole

• Plasmidesmate

What are the parts of the Nuclear envelope?

• outer membrain

• inner membrane

• nuclear pores

What are the parts of the endomembrane system?

• nuclear envelope

• endoplasmic reticulum

• golgi apparatus

• lysomes

• vacuoles

• plasma membrane

connected by transfer vesicles

What is the structure and function of the golgi apparatus

Cisternae pouches that transport, modify, and package - proteins and lipids into vesicles

The smooth cis face receives proteins and lipids

The trans face sends out modified vesicles

What is the structure and function of the Endoplasmic Reticulum

A smoother outer ER that produces other substances needed by the cell and DOES NOT have ribosomes

A rought ER that has ribosomes that create proteins

What is the structure and function of Lysosomes

An orb of membrane containing digestive enzymes that recycle old cell parts. Also help kill bactira this way

What is the structure and function a vacuole

Generally to take up space in a molecule allowing it to have a larger surface area for the amount of (non vacuole) components in the cell to get enough sustenance

What are the similarities between Mitochondria and Chloroplast?

Similarities:

• size

• double outer membrain

• grow and reproduce independently within cells

• have their own ribosomes and DNA molecules

What part of the Cytoskeleton is this (blue is nucleus)

Microtubules / Tubilin Polymers

What part of the Cytoskeleton is this

Microfilaments / Actin Filaments

What part of the Cytoskeleton is this

Intermediate Filaments

What are the functions of Microtubules, microfilaments, and intermediate filaments?

all are for maintenance of cell shape

Microtubules : Compression-resisting, Cell motility (ability to move), chromosome movments in cell division, organelle movements

microfilaments : tension-bearing, changes in cell shape, muscle contractions, division of animal cells

intermediate filaments: anchorage of nucleus and otehr organells, formation of nuclear lamina

Name that Animal cell part (and what its made of…)

Centrosome, made of two centrioles, made of microtubules

What two cell parts have this structure

basal body and motile cilium

Name that Animal cell part

Flagellum

Name that part of the Animals cells Extracellular Matrix

Proteoglycan complex

Name that part of the Animals cells Extracellular Matrix

Intergrins

Name that part of the Animals cells Extracellular Matrix

Plasma membrane

Name that part of the Animals cells Extracellular Matrix

Fibronectin

Name that part of the Animals cells Extracellular Matrix

Collagen

Name that part of the Animals cells Extracellular Matrix

Microfilaments

Name that part of the Animals cells Extracellular Matrix

Cytoplasm

Name that part of the Animals cells Extracellular Matrix

Extracellular fluid

What is a tight Junction?

a junction/structure that prevents fluid from getting between cells/ moving across a layer of cells

What is a gap junction?

A junction that allows ions and small molecules to move between cells

What is a Desmosomes

Anchors cells together, has intermediate filliments
