Male reproductive system

What membrane is visible? (broad term)

vaginal tunic

what membrane is continuous with the peritoneum?

vaginal tunic

What membrane is indicated by the green star?

parietal vaginal tunic

what membrane is indicated by the blue star?

visceral vaginal tunic

what is the space between the visceral vaginal tunic and the parietal vaginal tunic called?

vaginal cavity

green star

testes

blue star

epididymis

ductus deferens

What structure is the probe pointing to?

proper ligament of the testes

What structure is the probe pointing to?

ligament of the tail of the epididymis

red star, be specific

tail of epididymis

blue star, be specific

body of epididymis

green star, be specific

head of epididymis

pampiniform plexus

green star

vas deferens

blue star

pampiniform plexus

red star

mesoductus deferens

yellow star

mesorchium

entire structure

spermatic cord

cremaster muscle

What muscle is the cremaster muscle a slip of? (abbreviated)

IAO

prostate gland

underlying structure

pelvic urethra

covering muscle

urethralis m.

green region, be specific

root of the penis

blue region, be specific

body of the penis

red region, be specific

glans penis, free portion of the penis

green stars

left and right ischiocavernosus mm.

red stars

left and right bulbospongiosus mm.

brown star

left and right retractor penis mm.

left and right retractor penis mm.

green star

bulbos glandes

blue bracket

pars longa glandis

prepuce

green stars (structure)

bulb of the penis

yellow arrow

penile urethra

blue arrows

artery of the bulb

green stars (tissue type)

corpus spongiosum

green stars

left and right bulbospongiosus mm.

yellow stars (structure)

left and right crus of the penis

red stars

left and right ischiocavernosus mm.

blue arrows

deep arteries of the penis

yellow stars (tissue type)

corpus cavernosum

red stars (structure)

left and right crus of the penis

red stars (tissue type)

corpus cavernosum

green stars

left and right ischiocavernosus mm.

yellow star (structure)

bulb of the penis

yellow star (tissue type)

corpus spongiosum

blue stars

left and right bulbospongiosus mm.

white arrow

penile urethra

red star - what artery would be found here?

deep arteries of the penis

yellow star - what artery would be found here?

arteries of the bulb

green star

left and right retractor penis mm.

blue arrow

corpus spongiosum

red arrows

corpus cavernosum

yellow arrows

tunica albuginea

white arrow

penile urethra

blue star

corpus spongiosum

yellow arrow

os penis

the structure signified by the yellow arrow is a continuation of what tissue?

corpus cavernosum

red arrow

penile urethra

red arrow (structure)

penile urethra

yellow arrows (tissue)

corpus spongiosum

green star

os penis
