Anchors and Fasteners

Shear Load

Tension Load

Shear and Tension Load

Powder-Actuated Fasteners

Nail-In Anchor (Smack Pin)

Stud/Wedge Anchor

Drop-In Anchors

Sleeve Anchor

Adhesive Anchor

Anhesive Anchor

Lag Bolt

Wood Screws

Stove Bolts

Machine Screw (Tapped Hole)

Machine Screw

Thread Forming (Type-B)

Thread Forming (Type-AB)

Thread Cutting

Self Drilling

Self Piercing

A countersunk head with a flat top.

Flat

A countersunk head with a rounded top.

Oval

A slightly rounded head with short vertical side.

Pan

An extra wide head with a rounded top.

Truss

A domed head.

Round

A hexagonal head.

Hex

A hex head with built in washer.

Hex Washer

A hex head with built in washer and a slot.

Slotted Hex Washer

A small cylindrical head using a socket drive.

Socket

A low-profile rounded head using a socket drive.

Button

An X-shaped drive.

Phillips

A slot in the head

Slotted

A combination of Slotted and Philips drives.

Combination

A hexagonal hole for use with an Allen wrench.

Hex or Allen

Installs with a normal slotted driver but can not be removed without special tools.

One Way

A square shaped drive.

Robertson

A six-pointed star pattern specifically designed to prevent stripping.

Torx

Rivet Set

Pneumatic Rivet Gun

Pan - Universal Tinners Rivet
