Pink


Yellow (not gold)


Blue


Green


Gold circles


Dark blue


Two dots


Red


Gold
Labial/Buccal Sulcus (Or Vestibule)


Peach
(or vibrating line)


Black
Lingual Sulcus (Or Vestibule)


Dark Blue


Green


Brown

What does PMMA stands for? What is it?
Polymethyl Methacrylate; fabricates denture material
What are the steps in denture fabrication (clinical + laboratory)? (Only up until final insert)
(Clinical) Prelim appt for prelim impressions
(Lab) Prelim models for custom trays
(Clinical) Final impression
(Lab) Final models for Occlusal rims (bite blocks)
(Clinical) Occlusal rims and bite registration
(Lab) Articulation (mounting), Teeth set-up, denture wax try-in
(Clinical) Denture try-in
(Lab) Fabrication of final
(Clinical) Final Insert
What are the steps in denture fabrication (Week 1 slide 6)?

What are the three types of impressions we learn?
Alginate, PVS, PVS as bite registration
What does hydriocolloid mean?
water-attracting substance that forms a gel when it absorbs liquid
How would you describe the quality of the impression for alginate?
Reasonable
How do you handle alginate on the clinical side?
Once alginate impression has been taken, it needs to be disinfected —> impression wrapped in moist paper towel —> ziplock bag + lab script + lab case —> if not, it can be stored in fridge for 12-72 hrs without distortion
What does PVS stand for?
Polyvinyl Siloxane
T/F: PVS is hydrophobic, does not like to react with water
True
What is the steps of handling alginate in the labratory?
Receive case —> Disinfect —> Rinsed and inspected for voids and distortions —> pour the impression —> trimmed
What is bite registration used for?
To lock a patient’s VDO
What does VDO stand for?
vertical dimension of occlusion
What does border moulding help with?
For capturing frenum and all muscle attachments
In dentures, you will use a handpiece to trim what?
Stone and acrylic

What instrument is this
#7

What instrument is this?
Zahle Carver

What instrument is this?
Fhanstock
What are the steps of custom try fabrication (starting at the prelim model)
Mark the deepest park of the sulcus and 2mm above —> adapt wax to maxilla and mandible to sulcus —> cut out 4 squares on the ridge of each model —> apply vaseline —> adapt photo-base light cure material on top—> make handles —> 4-min cure with model —> 1-min cure intaglio surface —> rinse off residual wax on model and tray —> trim off frenums and trim to 2mm short of sulcus —> buff up
What angle should the handle be for maxillary custom tray? For the mandible?
45 deg from the incisive papilla; 90 deg from centre of ridge
What should the dimensions be for handles?
height— approx. 18mm — final15mm
width — approx. 10 mm — final 7mm
thickness — approx. 6mm — final 4mm
What can happen after tooth loss?
Mesial drift, bone resorption (happens right away), gum disease, misalignment, over-eruption
What direction does bone loss affect the maxilla? Mandible?
Maxilla shrinks to a narrow and shorter appearance
Mandible shrinks to a wider and shorter appearance
What shrinks (bone resorption) more, maxilla or mandible? Why?
Maxilla due to its mass, less dense and more cancellous bone
T/F: The bone resorption on the mandible that results in a pointy chin is an illusion
True
Clinically, what is measured from the occlusal rims? And what are they?
Centric occlusion — occlusal contact
Centric relation — the position of mandibular condyle in the glenoid fossa
Midline — the medial plane
Cuspid Line — where the canines are gonna be
VDO — vertical dimension of occlusion is the amount of vertical separation of the maxilla and mandible when the teeth are in occlusion
VDR — vertical dimension of rest is the amount of separation when mandible is at physiologic rest
Bite Registration — to record and hold everything into place
What is a postdam?
raised lip of acrylic engineered into the very back edge of an upper complete denture for continuous suction
What are the types of PVS for the final impression?
Light body, Medium body, Heavy body, Extra-light body
What is our curing light called?
Triad Light Cure Unit
What is high lipline vs. low lipline?
The position of the lip at full smile vs at rest

Label this
Electric Water Valve
Sediment Tray
Splash Shield
Angleguide
Orthodontic Work Table
Water Spray Attachment
Vertisquare
70mm Template
Difference between the Vertisquare and the Angleguide on a model trimmer?
Vretisquare is more of a shock-absorber in order to trim the base
The Angle guide helpd trim the model at the proper angle
What are the steps of fabrication of maxillary occlusal rim? (After final impressions have been poured up)
mark sulcus + deepest part of the sulcus + centre of ridge—> carve out postdam —> block out undercuts with wax —> vaseline —> adapt light-cure base plate —> cure 4 mins + 1 intaglio —> steam out excess wax —> plate should be up to sulcus, trim off sharp edges and frenums —> buff up melt folded wax over model —> use rim former to melt occlusal surface up to 22mm from deepest part of sulcus —> carve out posterior width to 8-10mm and anterior to 4-6mm —> angle anterior lip outwards for lip support —> smoothen surface using alcohol torch
What are the steps of fabrication of mandibular occlusal rim? (After final impressions have been poured up)
mark sulcus + deepest part of the sulcus + 2/3 of retromolar pad —> block out undercuts with wax —> vaseline —> adapt light cure baseplate —> cure 4 mins + 1 intaglio —> steam out excess wax —> plate should be up to sulcus, trim off sharp edges and frenums —> buff up —> melt folded wax over model —> use rim former @ 2/3 retromolar pad to melt occlusal surface up to 18mm from deepest part of the sulcus —> carve out posterior width to 8-10mm and anterior to 4-6mm —> smoothen surface using alcohol torch
