49 Terms

1
New cards

Simple

Made of one single layer of cells

<p>Made of <strong>one single layer</strong> of cells</p>
2
New cards

Stratified

Made of two or more layers of cells; only the deepest layer rests on the basement membrane

<p>Made of <strong>two or more layers</strong> of cells; only the deepest layer rests on the basement membrane</p>
3
New cards

Squamous

scale like (flat/disk-shaped)

<p>scale like (flat/disk-shaped)</p>
4
New cards

Cuboidal

cube like

<p>cube like</p>
5
New cards

Columnar

column-shaped

<p>column-shaped</p>
6
New cards
<p>Tissue: </p>

Tissue:

Simple Squamous Epithelium (40x)

7
New cards
<p>Cells:</p>

Cells:

Squamous

8
New cards
<p>Structure(s): (black)</p>

Structure(s): (black)

Plasma Membrane

9
New cards
<p>Structure(s): (green)</p>

Structure(s): (green)

Cytoplasm

10
New cards
<p>Structure(s): (red)</p>

Structure(s): (red)

Nucleus

11
New cards
<p>Tissue:</p>

Tissue:

Simple Cuboidal Epithelium (40x)

12
New cards
<p>Cell(s): (green)</p>

Cell(s): (green)

Cuboidal cells

13
New cards
<p>Structure(s): (blue)</p>

Structure(s): (blue)

Nucleus

14
New cards
<p>Structure(s): (black)</p>

Structure(s): (black)

Cytoplasm

15
New cards
<p>Structure(s): (red)</p>

Structure(s): (red)

Plasma membrane

16
New cards
<p>Tissue: </p>

Tissue:

Simple Columnar Epithelium (40x)

17
New cards
<p>Cell(s): (orange)</p>

Cell(s): (orange)

Columnar cells

18
New cards
<p>Cell(s): (black)</p>

Cell(s): (black)

Goblet Cells

19
New cards
<p>what tissue is in the green?</p>

what tissue is in the green?

connective tissue

20
New cards
<p>Tissue name as whole this is 10x</p>

Tissue name as whole this is 10x

Pseudostratified Ciliated Columnar Epithelium(10x)

21
New cards
<p>Tissue green section?</p>

Tissue green section?

Pseudostratified Ciliated Columnar Epithelium(10x) (green)

22
New cards
<p>Tissue red section?</p>

Tissue red section?

loose Connective tissue (10x) (red)

23
New cards
<p>Tissue green text section?</p>

Tissue green text section?

Hyaline cartilage

24
New cards
<p>Tissue green <em>section</em></p>

Tissue green section

Pseudostratified Ciliated Columnar Epithelium(40x),

25
New cards
<p>Structure(s): (red section)</p>

Structure(s): (red section)

Basement membrane (40x)

26
New cards
<p>Cell(s) green circle</p>

Cell(s) green circle

Goblet Cell (inside columnar cells)

27
New cards
<p>Structure(s): (black)</p>

Structure(s): (black)

Cilia

28
New cards
<p>Tissue:</p>

Tissue:

Striated (skeletal) muscle

29
New cards
<p>cell: (blue)</p>

cell: (blue)

Muscle Fiber

30
New cards
<p>Structure: (green)</p>

Structure: (green)

Nucleus

31
New cards
<p>Tissue: </p>

Tissue:

Tissue: Cardiac Muscle

Cell: Muscle Fiber

Structure: nucleus

32
New cards
<p>Tissue:</p>

Tissue:

Tissue: Smooth Muscle

Cell: Muscle Fiber

Structure: Nucleus

33
New cards
<p>Three major layers of the skin:</p>

Three major layers of the skin:

1. Epidermis (top)

2. Dermis (middle)

3. Hypodermis (bottom)

34
New cards
<p>Epidermis 4 minor layers (<strong>C</strong>ome <strong>G</strong>et <strong>S</strong>ome <strong>B</strong>eer)</p><p></p>

Epidermis 4 minor layers (Come Get Some Beer)


1. Stratum corneum

2. Stratum granulosum

3. Stratum spinosum

4. Stratum basale

<p>1. Stratum corneum</p><p>2. Stratum granulosum</p><p>3. Stratum spinosum</p><p>4. Stratum basale</p>
35
New cards
<p>The topmost layer of the Dermis is called:</p>

The topmost layer of the Dermis is called:

Dermal Papillae

<p>Dermal Papillae</p>
36
New cards
<p>Identify the following <strong><em>layers</em></strong></p>

Identify the following layers

1. Epidermis (top)

2. Dermis (bottom)

37
New cards
<p>Identify theses <strong><em>tissues</em></strong></p>

Identify theses tissues

  1. Stratified Squamous Epithelium (epidermis)

  2. Dense Irregular Connective Tissue (dermis)


38
New cards
<p>Layers of Epidermis (red)</p>

Layers of Epidermis (red)

Stratum Corneum

39
New cards
<p>Layers of Epidermis (yellow)</p>

Layers of Epidermis (yellow)

Stranum Granulosum

40
New cards
<p>Layers of Epidermis (green)</p>

Layers of Epidermis (green)

Stratum Spinosum

41
New cards
<p>Layers of Epidermis (lower red arrow)</p>

Layers of Epidermis (lower red arrow)

Stratum Basale

42
New cards

The topmost layer of the Dermis is called:


1. Dermal Papillae

<p>1. Dermal Papillae</p>
43
New cards
<p>Identify the green structure</p>

Identify the green structure

Hair follicle

44
New cards
<p>Identify the black structure</p>

Identify the black structure

Papilla of a Hair

45
New cards
<p>What structure is AMP?</p>

What structure is AMP?

AMP is arrectus pili muscle, pulls hair follicle upright

46
New cards
<p>Identify the red structure</p>

Identify the red structure

Hair Root

47
New cards
<p>Identify black structure, what layer is it in, and what’s above that?</p>

Identify black structure, what layer is it in, and what’s above that?

Sebaceous Gland it is in the Dermis layer (orange) and above that is the Epidermis (black)

48
New cards
<p>what structure is portrayed in green?</p>

what structure is portrayed in green?

Sudoriferous Gland (can also see sebaceous Gland by it both in Dermis)

49
New cards
<p>What two structures are these (green) (red)</p>

What two structures are these (green) (red)

Sudoriferous Gland (green)

Sebaceous Gland (red)
