Practicle 1 A&P

What is this tissue?

Artery

Name the structures.

1. Tunica externa (loose connective tissue)

2. Tunica media (smooth muscle)

3. Tunica íntima (simple squamous epithelium)

4. Lumen

What tissue is this?

Esophagus

Name the structures.

1. Lumen

2. Stratified squamous epithelium

3. Connective tissue

What tissue is this?

Renal tubule

Name the structures.

1. Connective tissue

2. Simple cuboidal epithelium

3. Lumen

What tissue is this?

Urinary bladder

Name the structures.

1. Connective tissue

2. Basal lamina

3. Transitional epithelium

4. Lumen

What tissue is this?

Jejunum (part of the small intestine)

name the structures.

1. Goblet cell

2. Lumen

3. Basal lamina

4. Simple columnar epithelium

5. Nuclei

6. Microvilli brush border

7. Intestinal villi

What tissue is this?

Trachea

Name the structures.

1. Nuclei

2. Goblet cell

3. Connective tissue

4. Basal lamina

5. Pseudostratified columnar epithelium

6. Cilia

7. Lumen

What tissue is this?

Areolar tissue

Name the structures.

1. Collagen fibers

2. Elastic fibers

3. Fibroblast nucleus

What tissue is this?

Adipose tissue

Name the structures

1. Adipocytes

2. Nuclei

What tissue is this?

Reticular tissue

Name the structures.

1. Reticular fibers

What tissue is this?

Tendon (dense regular connective tissue)

Name the structures.

1. Collagen fibers

2. Fibroblast nuclei

What tissue is this?

Dense irregular connective tissue

Name the structures.

1. Fibroblast nuclei

2. Collagen fibers

What tissue is this?

Hyaline Cartilage

Name the structures.

1. Matrix

2. Chondrocytes

What tissue is this?

Fibrocartilage

Name the structures.

1. Chondrocytes

2. Collagen fibers

what tissue is this?

Ground bone

Name the structures.

1. Osteon

2. Lacunae

3. Lamellae

4. Central canal

What tissue is this?

Blood

Name the structures.

1. Plasma

2. White blood cells (leukocytes)

3. Red blood cells (erythrocytes)

4. Platelets (thrombocytes)

What is the tissue?

Skin of the sole of the foot

Name the structures.

1. Keratinized layer of epithelium

2. Stratified squamous epithelium

3. Connective tissue

What is this tissue?

Skin of the sole of the foot (400x)

Name the structures.

1. Stratified squamous epithelium

2. Connective tissue

What tissue is this?

Skin of the scalp

Name the structures.

1. Basal lamina

2. Lumen of the sweat gland duct

3. Connective tissue

4. Stratified cuboidal epithelium

What tissue is this?

Elastic cartilage

Name the structures.

1. Perichondrium

2. Elastic fibers

3. Chondrocyte

4. Lacunae

What tissue is this?

Epidermis of thick skin

Name the structures.

1. Stratum corneum

2. Stratum basale

3. Stratum lucidum

4. Stratum granulosum

5. Spinosum

What tissue is this?

cutaneous membrane and hypodermis

Name the structures.

1. Hypodermis

2. Epidermis

3. Dermis

Name the structures.

1. Epidermal ridges

2. Free nerve ending

3. Arrector Pili muscle

4. Sebaceous gland

5. Merocrine sweat glad

6. Lamellated corpuscle

7. Tactile corpuscle

8. Tactile discs

9. Epidermis

10. Papillary layer of dermis

11. Reticular layer of dermis

12. Hypodermis

What tissue is this?

Skin of the scalp, thin skin

Name the structures.

1. Epidermis

2. Dermis

3. Hypodermis

4. Sebaceous gland

5. Arrector Pili muscle

6. Merocrine sweat gland

7. Hair follicles

8. Hair matrix

9. Hair papilla

What tissue is this?

Skin of the scalp, thin skin

Name the structures.

1. hair shaft

2. Sebaceous gland

3. Arrector Pili muscle

4. Merocrine gland

5. Epidermis

6. Hair follicle

7. Hair root

What is this?

Nail

Name the structures.

1. Nail plate

2. Nail bed

3. Lateral nail folds

4. Phalanx (bone of fingertip)

Name the structures.

1. Nail root

2. Eponychium

3. Phalanx

4. Nail bed

5. Nail plate

6. Hyponychium

7. Epidermis

8. Dermis

9. Nail matrix

Name the structures.

1. Nail plate

2. Free edge

3. Lunula

4. Eponychium (cuticle)

Name the structures.

1. Maxilla

2. Mental foramen

3. Frontal bone

4. Zygomatic bone

5. Mandible

Name the structures.

1. Frontal bone

2. Nasal

3. Sphenoid

4. Zygomatic bone

5. Parietal bone

6. Temporal bone

7. Zygomatic arch

Name the structures.

1. Coronal suture

2. External acoustic meatus

3. Squamous suture

4. Mastoid process

Name the structures.

1. Parietal bone

2. Sagittal suture

3. Lambdoid suture

4. Occipital bone

5. External occipital protuberance

Name the Structures.

1. Condylar process

2. Coronoid process

3. Mental foramen

Name the structures.

1. Superior nasal conchae

2. Middle nasal conchae

3. Inferior nasal conchae

Name the structures.

1. Ethmoid bone

2. Infraorbital canal

3. Optic canal

4. Lacrimal bone

Name the structures.

1. Palatine bone

2. Vomer

3. Foramen ovale

4. Foramen magnum

5. Occipital condyle

6. Styloid process

7. External occipital crest

8. Mastoid process

9. Stylomastoid foramen

10. Mandibular fossa

11. Jugular foramen

12. Foramen lacerum

13. Zygomatic Arch

Name the structures.

1. Crista galli

2. Cribriform plate

3. Sella turcica

4. Petrous ridge

5. Greater wing of the sphenoid

6. Lesser wing of the sphenoid

What bone is it?

Atlas (C1)

Name the structures.

1. Anterior arch

2. Posterior arch

what bone is it?

Axis (C2)

Name the structures.

1. Dens

What is the bone?

Cervical vertebrae (C3-C6) C7 is different

Name the structures.

1. Bifid spinous process

2. Vertebral foramen

3. Costal process

4. Vertebral body

5. Transverse foramen

What bone is this?

Thoracic vertebrae (superior view)

Name the structures.

1. Spinous process

2. Transverse process

3. Superior costal facet

4. Vertebral body

5. Vertebral foramen

6. Superior articular facet

Name the structures.

1. Transverse costal facet

2. Superior costal facet

3. Vertebral body

4. inferior costal facet

5. Spinous process

6. Transverse process

What bone is this?

Lumbar vertebrae (superior view)

Name the structures.

1. Transverse process

2. Spinous process

3. Pedicle

What bone is it?

Sacrum (anterior view)

Name the structures.

1. Ala

2. Sacral foramina

3. Coccyx

4. Transverse lines

Name the structures.

1. Medial sacral crest

2. Coccyx

Posterior view

Name the structures.

1. Vertebrosternal ribs (true ribs) 1-7

2. Vertebrochondral (false) 8-10

3. Floating ribs 11-12

Name regions and number.

1. 7 cervical

2. 12 thoracic

3. 5 lumbar

Name the structures.

1. Jugular notch

2. Manubrium

3. Body

4. Xiphoid process

5. Sternum

what bone?

Rib

Name the structures?

1. Shaft of rib

2. Tubercle of rib

3. Neck of rib

4. Head of rib
