Skull bones (interior, inferior, and anterior views)

A

Zygomatic bone

B

Sphenoid

C

Mandibular fossa

D

Jugular foramen

E (hard to see here; it’s a thin, pointy process extending from the temporal bone)

Styloid process

F

Temporal bone

H

Hypoglossal canal

I

Condyloid fossa

J

Lambdoid suture

K

Superior nuchal line

L

External occipital protuberance

M

Incisive fossa

N

Maxilla

O

Palatine bone

P

Medial and lateral pterygoid processes

Q

Zygomatic arch

R

Vomer

S

Foramen ovale

T

Foramen spinosum

U

Foramen lacerum

V

Carotid canal

W

Mastoid process

X

Occipital condyle

Y

Foramen magnum

Z

Occipital bone

A

Frontal sinus

B

Frontal bone

C

Sphenoid

D

Foramen ovale

E

Foramen spinosum

F

Carotid canal

G

Temporal bone

H

Mastoid foramen

I

Hypoglossal canal

J

Crista galli

K

Cribiform plate

L

Sella turcica

M

Foramen lacerum

N

Parietal bone

O

Jugular foramen

P

Foramen magnum

Q

Occipital bone

A

Frontal bone

B

Parietal bone

C

Supraorbital foramen

D

Temporal bone

E

Sphenoid

F

Zygomatic bone

G

Infraorbital foramen

H

Mastoid process

I

Maxilla

J

Mental foramen

K

Mandible

L

Coronal suture

M

Nasal bone

N

Frontonasal suture

O

Optic canal

P

Superior orbital fissure

Q

Lacrimal bone

R

Middle nasal concha

S

Temporal process

T

Inferior nasal concha

U

Perpendicular plate of ethmoid

V

Vomer

W

Mental protuberance
